800 - 1000 MHz Narrow Band LNA P1dB 27 dBm 4.2dB Low Noise Figure Amplifiers for Electronic Warfare and Military
  • 800 - 1000 MHz Narrow Band LNA P1dB 27 dBm 4.2dB Low Noise Figure Amplifiers for Electronic Warfare and Military
  • 800 - 1000 MHz Narrow Band LNA P1dB 27 dBm 4.2dB Low Noise Figure Amplifiers for Electronic Warfare and Military
  • 800 - 1000 MHz Narrow Band LNA P1dB 27 dBm 4.2dB Low Noise Figure Amplifiers for Electronic Warfare and Military

800 - 1000 MHz Narrow Band LNA P1dB 27 dBm 4.2dB Low Noise Figure Amplifiers for Electronic Warfare and Military

Place of Origin China
Brand Name SWT
Model Number SWT-1-18
Product Details
Operating Frequency:
800-1000 MHz
RF Input Power:
+17 DBm
Supply Voltage:
+6.0 V
P1dB:
+27 DBm
Gain:
18.5 DB
Input VSWR:
2.2:1
Output VSWR:
2.2:1
Operating Temperature:
-40 °C To +85 °C
Applications:
Wireless Communication,Radar Systems,Test And Measurement Equipment,Electronic Warfare And Military Applications
Packing:
Standard Packing
High Light:

800MHZ Band Power Amplifier

,

1000MHZ L Band Power Amplifier

,

27dBm rf antenna amplifier

Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
Product Description

800 - 1000 MHz Narrow Band LNA P1dB 27 dBm 4.2dB Low Noise Figure Amplifiers for Electronic Warfare and Military



Description

The 800 - 1000 MHz Narrow Band Low Noise Amplifier (LNA) is a high-performance RF amplifier designed for applications requiring low noise, high linearity, and high power output within this frequency range. Key performance indicators and features are as follows:

Key Features

  1. Frequency Range:

    800 - 1000 MHz, covering common UHF bands, suitable for various communication and signal processing applications.
  2. Low Noise Figure:

    The amplifier features an extremely low noise figure, ensuring excellent signal amplification even at low signal strengths.
  3. High Power Output:

    P1dB output power is 27 dBm, indicating the amplifier's output power at the 1 dB compression point, ensuring performance stability in high-power applications.
  4. Linearity:

    Excellent linearity, suitable for systems requiring high-fidelity signal transmission, such as wireless communications and radar systems.
  5. Reliability:

    Robust design capable of reliable operation under various environmental conditions.

Applications

  1. Wireless Communication:

    Suitable for cellular base stations, radio signal relays, satellite communications, enhancing signal reception and transmission quality.
  2. Radar Systems:

    Applied in radar signal processing, effectively improving target detection and tracking capabilities.
  3. Test and Measurement:

    Used in laboratory test equipment and field measurement instruments, providing high-precision signal amplification.
  4. Electronic Warfare and Military Applications:

    Suitable for signal amplification and interference signal suppression in electronic warfare systems, improving overall system performance.

Technical Specifications

  • Frequency Range: 800 - 1000 MHz
  • Gain: Specific gain value varies by model
  • Noise Figure: Extremely low, ensuring signal quality
  • P1dB Output Power: 27 dBm
  • Power Supply Voltage: Varies by model
  • Operating Temperature Range: Suitable for different environmental requirements

Summary

The 800 - 1000 MHz Narrow Band Low Noise Amplifier, with its superior low noise performance, high output power, and wide range of applications, is a key component in various high-performance RF systems. Whether in wireless communications, radar systems, or test and measurement equipment, this amplifier provides a reliable signal amplification solution.



Electrical Specifications @ +25 °C, ZS = ZL = 50 , Vcc=+5V



Parameter

Unit Minimum Typical Maximum
Frequency Range MHz 800   1000
Gain f = 800MHz dB   19.5
f = 850MHz dB 19.0
f = 900MHz dB 18.5
f = 950MHz dB 17.5
f = 1000MHz dB 16.5
P1dB dBm   +27
IP3 dBm   +37
Noise Figure dB   4.2 5.0
Reverse Isolation dB   -27
VSWR Input VSWR     2.2:1
Output VSWR 2.2:1
DC Power Supply V 4.5 5.0 5.5
Supply Current Quiescent (no RF) mA   100
@ P1dB = +27dBm mA 250




Absolute Maximum Ratings



Parameter Absolute Maximum
RF Input Power +17dBm
Supply Voltage +6.0V
Operating Temperature -40 °C to +85 °C
Storage Temperature -55 °C to +100 °C
