37.5-40.4 GHz Milimeter Wave Amplifers Psat 48 W LNA Low Noise Amplifiers
  • 37.5-40.4 GHz Milimeter Wave Amplifers Psat 48 W LNA Low Noise Amplifiers

37.5-40.4 GHz Milimeter Wave Amplifers Psat 48 W LNA Low Noise Amplifiers

Place of Origin China
Brand Name SWT
Certification CE
Model Number SW-PA-3750040500-45C
Product Details
Packing:
Standard Packing
Frequency Range:
37.5-40.4 GHz
Gain:
45 DB
Spurious:
60 DBc
Output Power (Psat):
48 Watt
VSWR:
2:1
Dimensions:
2U 19 Inch Rack Mount
Weight:
20000g
High Light:

37.5GHz Milimeter Wave Amplifers

,

40.4GHz Milimeter Wave Amplifers

,

31.6W low noise amplifier module

Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
Product Description



Millimeter Wave Amplifiers 37.5-40.4 GHz Past 48 W LNA Low Noise Amplifiers



Description

The module is designed for both military and commercial applications. The latest device technologies and design methods are employed to offer high power density, efficiency, and linearity in a small, lightweight package.



Specification

Specifications subject to change without notice. Typical performance at +28VDC +25℃, and in a 50Ω system.

ELECTRICAL SPECIFICATIONS@25
PARAMETER MIN TYPICAL MAX UNIT
Frequency Range 37.5   40.4 GHz
Gain 45     dB
Gain control       dB
Gain Flatness   /   dB
Noise Figure     / dB
Output Power (Psat) 48     Watt
Spurious     60 dBc
Harmonic       dBc
Input VSWR     2:1 Ratio
Output VSWR   1.8:1   Ratio
Input Voltage 230 ± 10% VAC, 47-53 Hz
Human-computer Interface touch screen LCD: Voltage,Current,Gain,FWD Power
Program Control Interfac RS422 and Ethernet



Note:

1. Forced air cooling.





ENVIRONMENTAL RATINGS
PARAMETER MIN TYPICAL MAX UNIT
Max Input power     +10 dBm
Operating Temperature -20   +50
Non-operating Temperature -40   +85
Relative humidity (non-condensing)   90   %
Altitude (MIL-STD-810F)   TBD   feet
Shock / Vibration (MIL-STD-810F)   TBD

MECHANICAL SPECIFICATIONS
PARAMETER VALUE LIMITS UNIT
Dimensions 2U Max Millimeter
Weight 20000 Max gram
RF Connectors Input WR22
RF Connectors output WR22
Forward / Reverse Detection Connectors
Impedance     Ohms
