80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication

80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication

Place of Origin China
Brand Name SWT
Model Number SW-PA-00801000-56C
Product Details
Frequency Range:
80-1000 MHz
PSat Power Output:
400 W
Power Gain:
56 DB
Power Gain Flatness:
±3.5 DB
Input VSWR:
2
Spurious Signals:
-65dBc
Harmonic Signals:
-15dBc
RF Connectors:
N-K / N-K (N Female)
Operating Voltage:
220V
In/Out Impedance:
50Ω
Operating Temp.:
-25~55°C
Dimensions:
482*550*223 Mm
Weight:
≤45 Kg
Highlight:

UHF 80mhz amplifier

,

UHF 1000mhz amplifier

,

400 W uhf rf amplifier

Payment & Shipping Terms
Minimum Order Quantity
1/pcs
Price
US Dollar (USD) 1-2/pcs
Packaging Details
Standard Packing
Delivery Time
5-8 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100pcs per month
Product Description

80-1000 MHz UHF Power Amplifier Psat 400 W RF Power Amplifier High Power for Satellite Communication

80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 0

Description

The Psat 400W 80-1000MHz UHF Power Amplifier is a specialized device designed to amplify radio frequency (RF) signals within the ultra-high frequency (UHF) range, specifically covering the frequency range of 80 megahertz (MHz) to 1000MHz with a Psat (saturated output power) of 400 watts (W).

  1. Frequency Range: This amplifier operates within the UHF frequency range, which typically spans from 300MHz to 3GHz. In this case, it specifically covers the range of 80MHz to 1000MHz, making it suitable for UHF applications such as broadcasting, telecommunications, and RFID systems.

  2. Saturated Output Power (Psat): The Psat of 400W indicates the maximum output power the amplifier can deliver before reaching saturation. This high power output makes it suitable for applications requiring strong signal transmission or testing within the UHF frequency band.

  3. Applications: The UHF Power Amplifier finds applications in various fields such as broadcast transmitters, UHF communication systems, radar systems operating in the UHF band, and scientific research where high-power UHF signals are required.

  4. High Frequency Range: Operating in the UHF band means that this amplifier is designed to handle signals in the higher frequency range efficiently, ensuring accurate amplification and signal integrity in UHF applications.

  5. Stability and Reliability: RF power amplifiers in this range are engineered for stability, reliability, and consistent performance over extended periods, crucial for maintaining signal quality and system reliability in UHF applications.

  6. Versatility: Despite its high power output and specific frequency range, this amplifier can be integrated into various RF systems and setups requiring amplification within the UHF band, offering flexibility and versatility in UHF signal amplification.

In summary, the Psat 400W 80-1000MHz UHF Power Amplifier is a powerful and specialized device tailored for UHF applications, providing high power output, stability, and reliability for demanding UHF communication, broadcasting, radar, and research systems operating within the specified frequency range.



Specification

Typical performance at 220V AC +25oC, and in a 50Ω system.



RF / ELECTRICAL
PARAMETER MIN TYP. MAX UNIT
Operating Frequency 80   1000 MHz
RF INPUT   0 5 dBm
Power Gain   56   dB
P-1dB Output Power   300   W
P-sat Output Power   400   W
Power Gain Flatness   ±3.5   dB
In/Out Impedance   50   Ω
Spurious Signals     -65 dBc
Harmonic Signals   -15   dBc
Gain Adjust Range   31.5
Gain Adjust Ste   0.5
Operating Voltage 200 220 240 V AC
Supply Power     3000 W
Input VSWR     2



MECHANICAL
PARAMETER VALUE UNIT
Dimensions (W x D x H) The standard 19-inch shelf is 5U high, 482*550*223 mm
RF Connectors (Input / Output) N-K / N-K (N female) --
Control Connector (Option1) DB9:Power on/power off control, gain control; Monitoring parameters include output power, temperature, supply voltage, and supply current --
Control Connector (Option2) RJ45:Remote control and monitoring can be realized through LAN
Cooling Built-in cooling system, forced air cooling --
Weight ≤45 kg
AC Connector Three-in-one air switch





ENVIRONMENTAL / PROTECTIONS
PARAMETER MIN MAX UNIT
Operating Temp. -25 +55 °C
Housing Temp. -45 +55 °C
Amplifier Safeguard Temp. +80 °C
Protections With over temperature protection, input over power protection, over voltage protection, over current protection, output mismatch protection



INPUT/OUTPUT panel Connector
AMPLIFIER CONNECTOR TYPE: ——
TRIAD CABLE PART NUMBER: ——
NUMBER interface type DESCRIPTION
X1N N-FK RF IN
X2 N-FK RF OUT
X3 LCD display Human-computer interaction interface
X4 Three-in-one air switch AC/220V/50Hz
X5 RJ45 LAN
X6 DB9 Control interface
X7 N-FK Forward coupling port
X8 N-FK Reverse coupling port





Connector Definition
AMPLIFIER CONNECTOR TYPE: DB9
TRIAD CABLE PART NUMBER: ——
NUMBER Definition DESCRIPTION
1 PA Enable TTL Hi= Enable, TTL Lo = Disable or No Connection
2 Output Power monitoring Output Power Detection (TTL Hi= Normal , TTL Lo =Fault )
3 Temp monitoring Temp monitoring alarm (TTL Hi= Normal , TTL Lo =Fault )
4 Voltage monitoring Voltage monitoring alarm (TTL Hi= Normal , TTL Lo =Fault )
5 Current monitoring Current monitoring alarm (TTL Hi= Normal , TTL Lo =Fault )
6 RXD RS232 serial bus interface, PA gain adjustment
7 TXD
8 GND
9 NC NC



80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 1

80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 2

80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 3

Our Company



80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 4

Shinewave Technology Co., Ltd, Nanjing is a company specializing in the research and development, production and sales of RF microwave passive components and subsystems. The company's product field covers a variety of microwave communication devices, including RF power amplifier, RF microwave filters, horn /Microstrip Antenna, isolators & Circulators, which are widely used in cellular wireless, aerospace, satellite, Mil-Spec, CATV/Broadband, RFID, test instrumentation, diagnostic imaging and many more fields worldwide.

In order to meet the special requirements of customers, in addition to standard products, we provide customized production solutions.

With experienced experts and specialists, our company has comprehensive production and strong design capabilities. Wholeheartedly, we provide customers with high-quality products and on time delivery services.

As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching Britain, America, Japan, Italy and south East Asia. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.





Participation in exhibitions



80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 5



Why choose us



Staffing
Over ten years' OEM/ODM experience.
R&D team with doctor,master degree talents.
Products covers a wide range of applications.

TECHNICAL SUPPORT
Fast Response
Provide Project Technical AdviceTo Provide Customers With Quality Pre-Sales/Post-Sales Service

PRODUCT SUPPLY
Full Spectrum Products Available
Customer Needs As A Guide
To Provide Customers With Customized Products And Solutions

PRODUCT QUALITY
All Have Passed Various Performance Tests Before DeliveryTo Ensure That The Product is Good And Stable During Use


Certifications

80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 6



Packing&Shipping

80-1000 MHz UHF Power Amplifier Psat 400 W High Power RF Power Amplifier for Satellite Communication 7

FAQ



Q1. Could I get a sample before bulk order?

Yes, we offer the sample for all models but charged.

Q2. What should I do if I don't know about frequency in my country?


Please feel free to contact us with your inquiry, we will find the frequency you need and offer help to your problems.


Q3. Do you accept OEM/ODM order?

Yes, we can customize the brand logo, colors, and frequencies.



Q4.Shipment Date



Sample 20 business days
≤50 pcs 60 business days
>50 pcs 90 business days
>200 pcs Negotiate





Q5: Delivery Date of the sample by DHL/FedEx

USA/Canada/Europe/Asia 3-5 days
Middle East/Latin American 5-7 days
African 3-7 days
